e90 coilover suspension kit

KW Coilover Kit - E90, E91, E92

by KW Automotive
$1,004.00 - $6,484.00
$1,004.00
$1,004.00 - $6,484.00
$1,004.00

H.A.S.  (Ultra - Street)

KW H.A.S. (Height Adjustable Spring) Coilover Sleeves offer height adjustment for use with OEM or aftermarket shocks. This budget-minded option does not include a shock absorber set like other KW Coilover kits but does still offer height adjustment with high quality components.

  • Individually height-adjustable - Front: .6"-1.2" / Rear: 0.2"-1.2"
  • Corrosion-resistant
  • Robust adjustable lowering mechanisms
  • Dirt-resistant trapezoid threads

Version 1 (Street)

The KW Variant 1 Coilover System is the ideal setup for customers who do not plan on tracking their car and want an adjustable ride height with a compliant ride. After extensive driving tests, KW engineers have set the dampers for the best balance between sporty driving, comfort, and safety.

  • Individually height-adjustable - Front: 1.2"-2.3" / Rear: 0.9"-2.1"
  • Chassis-specific pre-set damping for optimal performance
  • Corrosion-resistant KW “inox-line" stainless steel
  • Robust adjustment mechanisms
  • Dirt-resistant trapezoid threads
  • TÜV certified

Version 2 (Street/Trackday)

The V2 takes all of the features of the more basic V1 kit and adds rebound adjustment. It is the ideal setup for customers who want an adjustable ride height AND full rebound adjustment for precise suspension tuning to improve driving dynamics.

  • Individually height-adjustable - 1.2"-2.4" front, .8"-1.8" rear
  • Corrosion-resistant KW “inox-line" stainless steel
  • Adjustable rebound dampening technology
  • Robust adjustment mechanisms
  • Dirt-resistant trapezoid threads
  • TÜV certified

Version 3 (Trackday)

The V3 takes all of the features of the more basic V1 kit and adds full dampening adjustment for rebound AND compression adjustment for precise suspension tuning. This version requires a full rear Coilover conversion. You will need to reinforce your rear shock towers to run this kit.

  • Ride-height adjustable - 1.2"-2.4" front, .8"-1.8" rear
  • Infinitely variable rebound damping adjustment
  • 14-way adjustable compression damping
  • Unique, individually working damping force adjustment
  • Rear coilover conversion
  • Corrosion-resistant KW “inox-line" stainless steel
  • Ideal for street, high-performance and track driving
  • Robust adjustment mechanisms
  • TÜV certified

KW Clubsport Kit 2 Way (Full Track Spec)

KW Clubsport coilover suspension kit was developed for racing/track day events, specifically designed on the Nürburgring Nordschleife using track day tires. This kit comes with adjustable camber plates & features independently adjustable rebound and compression damper technology to allow a suspension setup according to the vehicle load, tire characteristics and different track conditions.

  • Height adjustment range - 1.2"-2.4" front, .8"-1.8" rear
  • Performance setup for the racetrack
  • 16-way adjustable rebound damping adjustment
  • 12-way adjustable compression adjustment
  • High performance linear race springs: Front 685 lbs/inch Rear Progressive.
  • Includes front camber plate mounts
  • Corrosion-resistant KW “inox-line" stainless steel
  • Robust adjustment mechanisms
  • TÜV certified

Benefits of Coilover Suspension

  • Ride height adjustment
  • Better handling and ride quality
  • Overall improved driving style

Fitment:
2006-2010 BMW E90 325i, 328i, 330i, 335i, 335d, M3

Notes:
Wheel spacers may be necessary if using stock tires/wheels. Images may vary.

Availability: As of 1/04 V1, V2 & V3 E9X non M kits are in stock. H.A.S. Kits are in stock. Please contact us before ordering. Lead times can take 6 to 8 weeks on out of stock kits. All refunds will incur a 10% cancellation request fee.
